SKU:3724418
F10-080-AF-CV-C-000-0000-P0
Availability
+ 18 days
Availability
Inventory
+ 18 days lead time
Express delivery in 1–2 business days is available for part of this quantity. For more information, contact info@hydtec.com or call +46 304 400 400.
For lead time: Call the sales team tel. +46 304 400 400 or send an email to info@hydtec.com.
Couldn't load pickup availability
Details
Details
Function
Motor
Displacement
78.6 cc / 4.80 cu.in.
Rotation variant
Reversible
Main port position
Rear ports – standard
Main ports
SAE 3/4" 6000 PSI / M10
Pilot diameter
160
Mounting flange
Cartridge 080
Shaft seal
High pressure FPM
Shaft type
Metric spline
Shaft size
W30x2x14x9g
Version code
000
Option 1
Standard (no option)
Option 2
Prepared for speed sensor
Weight
19.9
Weight UOM
KG
Country of origin
SWEDEN
Tariff code
84122981
Technical specification
Technical specification
Division (facet only)
Hydraulic Pump and Motor Europe
Division id
687925
Port type
Flange
Product series
Bent Axis Fixed Motors - Series F10
Region
EU
Specifications met
RoHS
Technology
Hydraulics
Url
Displacement
78.6 cm3/rev, 4.8 inch3/rev
Drain option
Yes
Shaft type
Spline
Mounting type
DIN
Weight
20.3 kg
Flow rate
306.5 L/min, 80.97 gal/min
Product type
Hydraulic Motor
Operating temperature
115 °C, 239 °F
For fluid type
Standard Hydraulic Fluids
Operating pressure
300 bar
Product style
Bent Axis, Fixed Displacement
No specifications found.
